TPU Polyurethane Cable Compound

YHS62023

This thermoplastic elastomer sealing strip compound adopts SEBS elastomer as base material, compounded with high-performance halogen-free flame retardants, antioxidants and other processing aids, then mixed, plasticized and pelletized. It delivers outstanding mechanical, electrical, flame-retardant and processing properties, featuring high flexibility, high resilience and scratch resistance. Customizable options including varied hardness, weather resistance, UV resistance and matte finish are available. Extruded strips have delicate appearance, smooth surface and comfortable touch. Recyclable, halogen-free, heavy-metal-free and phthalate-free, it complies with EU RoHS, REACH and other environmental directives.

✦ Thermoplastic elastomer sealing strip ✦ SEBS TPE ✦ high flexibility ✦ eco-friendly ✦ refrigerator seal ✦ automotive seal ✦ door window seal ✦ RoHS REACH compliant

Technical Data

Technical Specifications

Typical physical property data, subject to batch test reports.

Test project	Units	YHS62023
Density	g/cm3	0.98-1.25
Hardness	Shore A	40-98
Melt Finger (230 * 5KG)	g/10min	3.0
Original tensile strength	MPa	13.0
Original elongation at break	%	480
Air thermal aging	℃×h	136×168
Change rate of tensile strength	%	+4
Change rate of elongation at break	%	-16
Low temperature	℃	-40 pass
20℃ volume resistivity	Ω.cm	3.0×10¹⁵
Oxygen Index	%	-
Thermal deformation (90℃ * 4H)	%	13
Halogen acid gas content	mg/g	0
Flame retardant grade (single vertical)	-	-

⚠️ Note: The above data is a typical value obtained by testing the product and is not a standard for testing restrictions.

Recommended

Extrusion Process

When the storage time is long or the environment is relatively humid, or the product surface requirements are high, the pellets can be dried in a hot air hopper at 50-60 ° C for 1 to 2 hours before use.

It is recommended to use screw extrusion with L / D≥25 and compression ratio of 1.5 ~ 2.5: 1. The screw should be cleaned before extrusion to ensure the cleanliness of the product. It is recommended to use 80 mesh or 100 mesh filter to avoid impurities in the extrusion process, while ensuring the melt pressure to obtain a good appearance and material compactness. Because the difference between the actual temperature of the melt and the value indicated by the temperature control meter varies with the type of extruder, users are requested to choose the appropriate temperature according to the specific situation of the extruder used. The following temperatures can be used as a reference for commissioning:

Position	Cylinder I	Cylinder II	Cylinder III	Cylinder IV	Cylinder V	Head and mold
Temperature (℃)	160±10	175±10	185±10	190±10	195±10	200±10

Packaging & Storage

Packaging and storage

(25 ± 0.2) kg / bag, inner aluminum plastic composite bag, outer kraft paper bag (or customer specified packaging)
Stored in dry and ventilated place
Prevent sun, rain and water
Storage period is 6 months
