Data
Application
| Name | Item | Use |
|---|---|---|
| Flame retardant thermoplastic elastomer injection plastic | YHS62021 | Flame retardant UL94-V0 grade, computer, electronic connector, button, electrical support, tool handle, toy handle, etc. |
| Flame retardant thermoplastic elastomer injection plastic | YHS62021-1 | Flame retardant UL94-V1 grade, USB plug, headphone plug, power cord plug, etc. |
| Flame retardant thermoplastic elastomer injection plastic | YHS62021-2 | Flame retardant UL94-V2 grade, suitable for various injection molded parts with low requirements on flame retardant |
| Thermoplastic elastomer injection plastic | YHS62021-3 | High environmental protection, non-flammability, good processability, wide application range |
Technical Data
Technical Specifications
Typical physical property data, subject to batch test reports.
| Test project | Units | YHS62021 | YHS62021-1 | YHS62021-2 | YHS62021-3 |
|---|---|---|---|---|---|
| Density | g/cm3 | 1.05-1.25 | 1.00-1.25 | 1.00-1.25 | 0.96-1.15 |
| Hardness | Shore A | 65-98 | 65-98 | 60-98 | 30-98 |
| Melt Finger (230*5KG) | g/10min | 3.0 | 5.0 | 7.0 | 12.0 |
| Original tensile strength | MPa | 8.0 | 9.0 | 10.0 | 12.0 |
| Original elongation at break | % | 300 | 340 | 380 | 450 |
| Air thermal aging | ℃×h | 110×168 | 110×168 | 110×168 | 110×168 |
| Change rate of tensile strength | % | +8 | +10 | +11 | +13 |
| Change rate of elongation at break | % | -13 | -12 | -10 | -11 |
| Low temperature | ℃ | -40 pass | -40 pass | -40 pass | -40 pass |
| 20℃ volume resistivity | Ω.cm | 2.0×10¹⁴ | 4.0×10¹⁴ | 6.0×10¹⁴ | 3.0×10¹⁵ |
| Oxygen Index | % | 28 | 26 | 25 | - |
| Thermal deformation (90℃ * 4H) | % | 10 | 12 | 12 | 13 |
| Halogen acid gas content | mg/g | 0 | 0 | 0 | 0 |
| Flame retardant rating (UL94) | - | V-0 | V-1 | V-2 | HB |
⚠️ Note: The above data is a typical value obtained by testing the product and is not a standard for testing restrictions.
Recommended
Extrusion Process
When the storage environment is wet or the production surface is required to be high, the particles can be dried in a hot air hopper at 70 ℃ for 1-2 hours.
It can be processed by general injection molding machine. Because the difference between the actual temperature and the indicated value of the temperature control meter varies with the type of injection molding machine, users should choose the appropriate temperature according to the specific situation of the extruder . The following temperatures can be used as a reference for commissioning:
| Position | Feeding section | Middle section | Front section | Die section |
|---|---|---|---|---|
| Temperature | 160±10 | 180±10 | 190±10 | 200±10 |
Packaging & Storage
Packaging and storage
1
- (25 ± 0.2) kg / bag, inner aluminum plastic composite bag, outer kraft paper bag (or customer specified packaging)
- Stored in dry and ventilated place
- Prevent sun, rain and water
- Storage period is 6 months
